Ground mount systems

The optimised design of S-Rack Ground Mount Systems means fewer components and installation tools. This translates into considerable savings on materials and installation timeframes.

Use Our Calculator
Sigma S1 Alu Ground Mount Kit Calculator
Customer information
Company name:
Date:
Contact name:
Email:
Panel information
Panel orientation
Panel length
mm
Panel width
mm
Panel wattage
Wp
Project information
Wind region
Tilt angle
¡Æ
Panels per rows
pcs
Number of arrays
pcs
Method of Install
Project Summary
Tilt Angle: Module Wp: Total kWp: No of Tables
Total No of Modules: No of Rows: 2 Module per Row
Bill of Materials (BOM)
Item
S-Rack Article Number
Description
Length (mm)
Qty / unit
Total Qty[pcs.]
Spares [pcs.]
Qty Including Spares [pcs.]
1 01-001 C-Post 150x70x14x3.5mm 3750
2 806-0473 Hex head bolt M12x25
3 003-106 Flat Washer M12
4 003-108 Flange Nut M12
5 02-100 Girder Set 125x55x10x2 3395
6 03-100 Strut Set 60x30x3 2015
7 04-006 Module Support 45/75 5000
8 04-013 Module Support 45/75 Inner Connector
9 05-010 Hex Head self-tapping Screw 5.5x25
10 05-034 End Cap 4575 CS
11 05-109 Grounding lug
12 05-137 Adjustable End Clamp 30-40mm CS
13 05-116 Grounding Module Mid Clamp 30-45mm
Table Details
Post/Pile per table pcs
Maximum cantilever from first/last Pile* 750 mm
Panel clearance height 600 mm
Module Clamp Gap 19 mm
Actual post span mm
Table length mm
Pile Embedment Depth* mm
Purlin segmentation pcs
The following sample drawing is for illustration only.
**Cantilever from centre of last pile to end of purlin
*Please refer to Page 5 of the RMA certificate to confirm minimum embedment depths as per foundation type
